Stainless Steel Decanter Centrifuge for Serum Protein Extraction

What is the primary purpose of decanting?
Decanting enhances the wine's aromas and flavor. The pouring of wine from the bottle into a decanter introduces oxygen to the wine, allowing it to "breathe." The addition of air to the equation allows the wine's aromas to fully express themselves and the wine's unique flavors to knit and come forward.

• All parts directly touching material are made of stainless steel
• Continuous and automatic operation minimizes labor costs
• Two motor drive with adjustable bowl and screw speed via VFD
• Continuous spiral discharging with PLC control and touch screen operation
• Scroll conveyor coated with wearable alloy or welded with alloy plate (according to material characteristics and customer demand)
• Safety protections include: rotation rate detection, vibration protection, motor overload and overheat protection, scroll protection when zero differential speed occurs

The bowl and screw make high-speed rotation with a certain differential speed between them. The materials enter the bowl from the feed tube. Under centrifugal force, the liquid of higher specific weight accumulates on the inner walls of the bowl and is discharged through the centripetal pump or overflow plate. The liquids of lower specific weight form an inner liquid ring, stick to the surfaces of heavy liquids, and are discharged from the overflow channel. The spiral material pusher continuously pushes solids to the taper end of the bowl where they are discharged from the residue outlet after going through the drying area.

The LW series 2-phase sedimentation decanter centrifuge is a horizontal, continuously working and continuously spiral discharging sedimentation centrifuge, ideal for sewage sludge dewatering and thickening.

• All material contact surfaces made of high-quality stainless steel or duplex stainless steel
• Specially designed bowl and spirals press against dewatered cake at conical end for high dryness
• Double motor with double frequency conversion and multi-stage planetary gear drive
• Wide range of wear protection options including welded hard facing, spray coating, ceramic port, Zn carbide tiles, and chilled hard metal port castings

Huading Separator has been at the forefront of centrifugal separation technology for more than 60 years. Established in 1954, we are the leader in mechanical separating technology in China. Our machines serve diverse industries including beverage, dairy, oil recovery, chemicals, pharmaceuticals, biotechnology, starch technology, marine engineering, energy, oil fields, and water treatment.
